EXP170CE / EXS170CE-4 R600a LBP Compressor – 11.95cc

EXP170CE / EXS170CE-4 R600a refrigeration compressor for low-temperature LBP applications. This page is the main technical listing for the 11.95cc compressor and is intended for engineers selecting an exact or technically verified replacement.

EXP170CE / EXS170CE-4 technical specification

• Refrigerant: R600a
• Application: low back pressure (LBP)
• Displacement: 11.95cc
• Supply: 220–240V, 50Hz, single phase
• Motor / starting: RSIR, low starting torque, PTC device
• Expansion device: capillary tube
• Evaporating range: approximately -35°C to -15°C

Compatibility check

Compressor model names alone do not confirm a direct replacement. Before ordering, compare the original compressor label, refrigerant, displacement/capacity, operating range, starting device and pipe connections. If unsure, send Brave Coolers a clear photo of the original label.

Professional installation

R600a is highly flammable. Installation, evacuation, leak testing and charging must be completed by a competent refrigeration engineer using equipment suitable for flammable refrigerants.
