Tecnosystemi TS380 Condensate Tank Pump
£142.95 inc VAT
£119.13 ex VAT
TS380: 380 L/h published maximum flow; 6m maximum head. 230V 50Hz. See performance curves and installation requirements below.
Delivery options and applicable charges are shown at checkout. For urgent spare parts orders, contact us before 2:00 PM (Mon–Fri) to confirm stock and dispatch. Large equipment, cold rooms and special courier items have separate delivery arrangements.
Orders up to £60: £4.90. Orders over £60 up to £100: £6.95. Orders over £100: FREE. Based on the spare-parts total after discounts, including VAT. UK mainland, parcels up to 15kg; restricted destinations and heavier parcels require a quote.
Tecnosystemi TS380 Condensate Tank Pump
Range photograph shows the TS200/TS380 housing family; this listing is TS380.
Technical specification
- Brand: Tecnosystemi
- Model: TS380
- Maximum flow: 380 L/h
- Maximum head: 6m
- Supply: 230V 50Hz
- Tank: 1.7L
- Input power: 147W
- Protection: IPX4
- Maximum liquid temperature: 43°C
- Drain inlets: 3 × 29mm
- Outlet tube reference: 8mm internal / 12mm external
- Alarm contact: NC, 24V AC maximum — no direct mains connection
- Reference body W × H × D: 282 × 177 × 127mm; check mounting drawing
Included
Pump with reservoir and integral non-return valve.
Accessories / select separately
Select discharge hose, clamps, adaptors, fixings and a suitable alarm/control interface. Check the supplied assembly before ordering extra valves.
Setup and technical documents
Engineer selection and commissioning
Match condensate production to the performance curve at the actual lift, hose diameter and route. Do not assume maximum flow and maximum head occur together. Support the drainage, avoid kinks and allow service access. Follow the supplied wiring diagram and prove pumping, drainage and any high-level interlock with water before handover. Isolate power before servicing.
Delivery
Estimated delivery: 2 working days, subject to stock and postcode confirmation. Delivery charges shown at checkout.
| Weight | 2.1 kg |
|---|---|
| Brand | Tecnosystemi |
| Model | TS380 |
| Maximum flow | 380 L/h |
| Maximum head | 6m |
| Supply | 230V 50Hz |
| Tank | 1.7L |
| Input power | 147W |
| Protection | IPX4 |
| Maximum liquid temperature | 43°C |
Model compatibility and reference numbers
| OEM / part reference | Not specified — please confirm before ordering. |
|---|---|
| Listed brands | Not specified — please confirm before ordering. |
| Listed models | Not specified — please confirm before ordering. |
Reference numbers and brand names assist identification; they do not by themselves confirm fit or genuine OEM manufacture. Check the full model and part number, dimensions and electrical specifications. If unsure, send us a photograph of the rating plate and original part before ordering.
