Embraco EXP160CE-4 R600a LBP Compressor – 10.09cc

Embraco EXP160CE-4 hermetic compressor for compatible low-back-pressure R600a refrigeration systems. This page now uses the verified model specification; the previous ZEL HML200A image association has been removed.

EXP160CE-4 technical specification

• Refrigerant: R600a
• Application: low back pressure (LBP)
• Displacement: 10.09cc
• Commercial designation: 1/4−HP class
• Reference cooling capacity: 170W at ASHRAE -23.3°C / 54.4°C condition
• Supply: 220–240V, 50Hz, single phase
• Motor: RSIR, low starting torque
• Starting device: PTC
• Expansion device: capillary tube
• Evaporating range: approximately -35°C to -15°C

Compatibility check

Match the complete EXP160CE-4 reference and compare refrigerant, LBP duty, capacity, electrical components, mounting and pipe connections with the removed compressor. Contact Brave Coolers with a clear data-plate photo if you need help checking.

R600a installation safety

R600a is highly flammable. Installation, leak testing, evacuation and charging must be completed by a competent refrigeration engineer using hydrocarbon-safe tools and procedures.
