Jiaxipera TT1117GY R600a LBP Compressor – 11.2cc 1/5HP

Jiaxipera TT1117GY model-focused replacement listing for TAN6FNF, MBL1911FFR and MTM1912 model searches. This page supplies the TT1117GY compressor; the appliance wording does not guarantee fit, so check the removed compressor data plate before ordering.

TT1117GY technical specification

• Manufacturer: Jiaxipera
• Model: TT1117GY
• Refrigerant: R600a
• Application: low back pressure (LBP)
• Displacement: 11.2cc
• Nominal rating: 1/5HP
• Supply: 220–240V, 50Hz, single phase
• Reference cooling capacity: 198W at -23.3°C ASHRAE condition

Compatibility check

Match TT1117GY on the original compressor label and compare refrigerant, duty, electrical components, mounting and pipe connections. Appliance model references are search guidance only because production revisions can use different compressors.

R600a installation safety

R600a is highly flammable. Installation, leak testing, evacuation and charging must be completed by a competent refrigeration engineer using hydrocarbon-safe equipment and procedures.
